| Dimensions | 108" x 91" x 42" |
| Dimensions (Metric) | 274 cm x 231 cm x 96 cm |
| Seating Capacity | 9 |
| Lounge Seat | Yes |
| Jets | 71 |
| Water Volume | 505 gal / 1912 L |
| Dry Weight | 1210 lbs / 549 kg |
| Primary Pump | (5) 3.0 BHP 1-Spd (2) 0.25 HP 1-Spd |
| Water Management | WhisperPure™ Circulation System with Microfilter |
Features of the Pelican Bay
H2O PowerFlow Jet Design
The H2O PowerFlow Jet System delivers powerful, targeted hydrotherapy from head to toe. With customizable jets for the back, neck, feet, and lower body, each design provides optimal pressure and relief—helping to melt away tension, soothe tired muscles, and promote total body relaxation.
Dual Footblaster Jets
Treat yourself to the ultimate foot massage with the highly therapeutic Footblaster Jets. This innovative design features either one or two powerful jets that relieve tightness and relax muscles, melting away tension and pain in a matter of minutes. One soothing moment enjoying the Footblasters and you will agree that it is superior to any other foot massage.
Maximum Tapered ASTM Cover
The 5-inch Maximum Tapered ASTM Cover provides superior insulation and protection for your spa. Spa covers help protect your hot tub from debris and severe weather conditions, as well as extend its lifespan. A cover will also reduce the effects of evaporation while helping to maintain its proper chemical balance.
Full Foam
The full foam feature involves filling the spa cabinet with high-density foam insulation. This improves energy efficiency, structural support, and heat retention, making your spa more cost-effective and durable.
PermaBase ABS Pan
The PermaBase ABS Pan offers durable, long-lasting protection for your spa’s base.
WhisperPure™ Circulation System
The WhisperPure™ Circulation System with Microfilter ensures crystal-clear water by efficiently filtering impurities while operating quietly, providing a clean, relaxing, and serene spa experience.
Monarch Elite Cabinet
The Monarch Elite Cabinet features a refined, weather-resistant design that enhances both durability and visual appeal. Crafted for long-lasting performance in outdoor settings, this premium spa cabinet adds a sophisticated finish while protecting internal components from the elements.
AllegroFall
Dual jet pumps deliver powerful, customizable hydrotherapy, while the dedicated circulation pump ensures continuous water flow for optimal filtration, temperature uniformity, and clarity—maintaining peak performance and water quality between uses.
BellagioFalls
BellagioFalls features two adjustable arches of water. This dramatic effect enhances the environment of your spa, adding to your sensory experience.
DynaBrite™ LED
The DynaBrite Elite LED system features a 5-inch main LED light and five 2-inch accent LEDs, beautifully illuminating the BellagioFalls and 24” AllegroFall. This vibrant lighting enhances the spa’s ambiance, creating a stunning, customizable nighttime experience.
SpaTouch 2 Topside
The SpaTouch 2 Topside features a vibrant color LCD panel with 3-zone lighting control, WiFi readiness (with module), and a multi-language interface. This intuitive touchscreen offers seamless access to spa functions, making it easy to customize your experience with precision and ease.
Titanium Heater
The Titanium Heater delivers reliable, efficient performance with 5.5 kW power for North America (60 Hz) and 3.0 kW for export markets (50 Hz). Built for durability and corrosion resistance, it ensures consistent water temperature and long-lasting spa enjoyment in any environment.
Optional Upgrades
Stereo System
The Premium Infinity Sound System includes a Bluetooth receiver, AM/FM radio, USB, and auxiliary input, plus app compatibility. Equipped with four 2-inch Polk interior speakers and a powerful subwoofer, it also offers optional 6.5-inch Polk patio speakers for an enhanced, immersive outdoor audio experience.
BBA™2 Audio
The BBA™2 Audio System offers fully integrated Bluetooth streaming with premium sound quality. Featuring four 2-inch Polk interior speakers and a powerful subwoofer, it delivers rich, immersive audio—perfect for enhancing your spa experience with your favorite music or playlists.
Midnight Glow LED
The Midnight Glow LED+++ system features four corner cabinet lights and four side kick rail lights, creating a stunning, ambient glow around your spa.
Water Purification
Whether you choose to add Diamond AOP™, Crystal ProPure™ Ozone Mixing Chamber, or an Ozonator - each promotes water purification for a clean pool.
Pump/Heater Valves
Pump and heater valves provide precise water flow control, enhancing system efficiency and simplifying maintenance. Designed for durability and easy access, these valves help protect critical components like pumps and heaters, ensuring optimal spa performance and long-term reliability.
Worldwide WiFi App Module
The Worldwide WiFi App Module lets you control your spa remotely using a smartphone or tablet. Simply download the app to adjust temperature, jets, lighting, and more—anytime, anywhere—for ultimate convenience and a fully connected spa experience.
